제품 상세 정보:
|
| 부문 번호: | 2EDN8534F | Driven Configuration: | Low-Side |
|---|---|---|---|
| 전압 - 공급: | 4.5V ~ 20V | Logic Voltage - VIL, VIH: | 1.4V, 1.9V |
| Current - Peak Output (Source, Sink): | 5A, 5A | Rise / Fall Time (Typ): | 8.6ns, 6ns |
2EDN8534F Integrated Circuit Chip 5A Dual Channel Low Side EiceDRIVER Gate Driver IC
Product Description Of 2EDN8534F
2EDN8534F is EiceDRIVER™ 2EDN Gate Driver for MOSFETs and WBG switches. Fast dual-channel 5A gate driver optimized for driving both standard and super-junction MOSFETs, as well as wide band gap power switching devices.
Specification Of 2EDN8534F
| Part Number: | 2EDN8534F |
| MOSFET Gate Drivers | |
| Low-Side | |
| SMD/SMT | |
| DSO-8 | |
| 2 Driver | |
| 2 Output | |
| 5 A | |
| 8 V | |
| 20 V | |
| Non-Inverting | |
| 8.6 ns | |
| 6 ns | |
| - 40 ℃ | |
| + 150 ℃ | |
| Input Voltage - Max: | 20 V |
| Input Voltage - Min: | - 10 V |
| Logic Type: | CMOS |
| Operating Supply Current: | 900 uA |
| Product Type: | Gate Drivers |
| Propagation Delay - Max: | 25 ns |
| Rds On - Drain-Source Resistance: | 1.4 Ohms |
Features Of 2EDN8534F
Up to ±5 A source/sink currents
19 ns typ. propagation delay
+6/-4 ns propagation delay accuracy
1.8 µs output start-up time
500 ns output shut-down time
Active output voltage clamping
-12 V input robustness
5 A reverse current robustness
4 V and 8 V UVLO options
Applications Of 2EDN8534F
Server
Telecom
DC-DC Converters
Power tools
Industrial SMPS
Low speed electrical vehicles
Solar power inverter
LED lighting
