제품 상세 정보:
|
| 부문 번호: | L6699DTR | 전압 - 시동: | 10.7 Ｖ |
|---|---|---|---|
| 듀티 싸이클: | 50% | 전압 - 공급 (Vcc/Vdd): | 8.85V ~ 16V |
| 주파수 - 스위칭: | 60kHz ~ 235kHz | 작동 온도: | -40' Ｃ ~ 150' Ｃ (TJ) |
L6699DTR Integrated Circuit Chip High Voltage Resonant Controller SOIC16 AC DC Converters
Product Description Of L6699DTR
L6699DTR is a double-ended controller specific to series-resonant half bridge topology. Both LLC and LCC configurations are supported. L6699DTR provides symmetrical complementary duty cycle: the high-side switch and the low-side switch are driven ON/OFF 180° out-of-phase for exactly the same time. Output voltage regulation is obtained by modulating the operating frequency.
Specification Of L6699DTR
| Part Number: | L6699DTR |
| Product Category: | AC/DC Converters |
| SMD/SMT | |
| SOIC-16 | |
| 13.3 V | |
| 8.85 V | |
| 16 V | |
| 235 kHz | |
| 50 % | |
| 3 mA | |
| - 40 ℃ | |
| + 150 ℃ |
Features Of L6699DTR
Symmetrical duty cycle, variable frequency control of resonant half bridge
Self-adjusting adaptive deadtime
High-accuracy oscillator
2-level OCP: frequency-shift and immediate shutdown
Interface with PFC controller
Anti-capacitive-mode protection
Burst-mode operation at light load
Input for brownout protection or power-on/off sequencing
“Safe-start” procedure prevents hard switching at startup
600 V rail compatible high-side gate driver with integrated bootstrap diode and high dv/dt immunity
-300/800 mA high-side and low-side gate drivers with UVLO pull-down
SO16N package
Applications Of L6699DTR
SMPS for LCD TVs, desktop and AIO PCs, servers, Telecom power
AC-DC adapter, open frame SMPS
