제품 상세 정보:
|
| Part Number: | AD8607ARMZ | Amplifier Type: | CMOS |
|---|---|---|---|
| Output Type: | Rail-to-Rail | Current - Supply: | 40µA (x2 Channels) |
| Current - Output / Channel: | 70 mA | Operating Temperature: | -40°C ~ 125°C |
| 강조하다: | AD8607ARMZ precision op amp,MSOP8 operational amplifier chip,integrated circuit amplifier with warranty |
||
AD8607ARMZ Integrated Circuit Chip Operational Amplifiers MSOP8 Precision Op Amps Chip
Product Overviews Of AD8607ARMZ
AD8607ARMZ is dual micro-power rail-to-rail input and output amplifiers, respectively, that feature very low offset voltage as well as low input voltage and current noise.
Specification Of AD8607ARMZ
| Part Number: | AD8607ARMZ |
| Product Category: | Precision Amplifiers |
| 2 Channel | |
| 316 kHz | |
| 100 mV/us | |
| 12 uV | |
| 500 pA | |
| 5 V, 2.5 V | |
| 1.8 V, 900 mV | |
| 40 uA | |
| 70 mA | |
| 100 dB | |
| 25 nV/sqrt Hz | |
| MSOP-8 | |
| SMD/SMT | |
| No Shutdown | |
| - 40 ℃ | |
| + 125 ℃ | |
| Dual Supply Voltage: | 900 mV to 2.5 V |
| Height: | 0.85 mm |
| Input Voltage Range - Max: | 5.2 V |
| Length: | 3 mm |
| Maximum Dual Supply Voltage: | 2.5 V |
| Minimum Dual Supply Voltage: | 900 mV |
| Operating Supply Voltage: | 1.8 V to 5 V |
Features Of AD8607ARMZ
Low offset voltage: 50 µV max
Low input bias current: 1 pA max
Single-supply operation: 1.8 V to 5 V
Low noise: 22 nV/vHz
Micropower: 50 µA max
Low distortion
No phase reversal
Unity gain stable
Applications Of AD8607ARMZ
Battery-powered instrumentation
Multipole filters
Sensors
Low power ASIC input or output amplifiers
