제품 상세 정보:
|
| 부품 번호: | L6599ADTR | 출력 수 :: | 1 출력 |
|---|---|---|---|
| 스위칭 주파수:: | 500 킬로 헤르츠 | 듀티 사이클 - 최대 :: | 52 % |
| 출력 전압 :: | 13.3 Ｖ | 출력 전류 :: | 800 MA |
L6599ADTR Integrated Circuit Chip Improved High-Voltage Resonant Controller
Product Description Of L6599ADTR
L6599ADTR is a double-ended controller specific to series-resonant half bridge topology. It provides 50% complementary duty cycle: the high-side switch and the low-side switch are driven ON/OFF 180° out-of-phase for exactly the same time. Output voltage regulation is obtained by modulating the operating frequency. A fixed deadtime inserted between the turn-off of one switch and the turn-on of the other guarantees soft-switching and enables high-frequency operation.
Specifications Of L6599ADTR
|
Applications
|
Resonant Converter Controller
|
|
Voltage - Supply
|
8.85V ~ 16V
|
|
Current - Supply
|
3.5 mA
|
|
Operating Temperature
|
0°C ~ 105°C
|
Features Of L6599ADTR
50% duty cycle, variable frequency control of resonant half bridge
High-accuracy oscillator
Up to 500 kHz operating frequency
Two-level OCP: frequency-shift and latched shutdown
Interface with PFC controller
Latched disable input
Burst mode operation at light load
Input for power-ON/OFF sequencing or brownout protection
Non-linear soft-start for monotonic output voltage rise
600 V-rail compatible high-side gate driver with integrated bootstrap diode and high dv/dt immunity
-300/800 mA high-side and low-side gate drivers with UVLO pull-down
DIP16, SO16N package
Applications Of L6599ADTR
LCD and PDP TV
Desktop PC, entry-level server
Telecom SMPS
High efficiency industrial SMPS
AC-DC adapter, open frame SMPS
