제품 상세 정보:
|
| 부품 번호: | TOP258YN | 출력 전압 :: | 700 Ｖ |
|---|---|---|---|
| 출력 전원 :: | 195 Ｗ | 입력/공급 전압 - 최소:: | - 300mV |
| 입력/공급 전압 - 최대:: | 9 Ｖ | 스위칭 주파수:: | 132kHz |
TOP258YN Integrated Circuit Chip Integrated Off-Line Switcher With Advanced Feature Set And Extended Power Rang
Product Description Of TOP258YN
TOP258YN is Enhanced EcoSmart®, Integrated Off-Line Switcher withAdvanced Feature Set and Extended Power Range.
Specifications Of TOP258YN
|
Output Isolation
|
Isolated
|
|
Internal Switch(s)
|
Yes
|
|
Voltage - Breakdown
|
700V
|
|
Topology
|
Flyback
|
|
Duty Cycle
|
78%
|
|
Frequency - Switching
|
66kHz, 132kHz
|
|
Power (Watts)
|
195 W
|
|
Fault Protection
|
Current Limiting, Over Temperature, Over Voltage
|
|
Operating Temperature
|
-40°C ~ 150°C (TJ)
|
Features Of TOP258YN
Lower System Cost, Higher Design Flexibility
Multi-mode operation maximizes efficiency at all loads
New eSIP-7F and eSIP-7C packages
Low thermal impedance junction-to-case (2.C per watt)
Low height is ideal for adapters where space is limited
Simple mounting using a clip to aid low cost manufacturing
Horizontal eSIP-7F package ideal for ultra low height adapter and monitor applications
Extended package creepage distance from DRAIN pin to adjacent pin and to heat sink
No heatsink required up to 35 W using P, G and M packages with universal input voltage and up to 48 W at 230 VAC
Output overvoltage protection (OVP) is user programmable for latching/non-latching shutdown with fast AC reset
Allows both primary and secondary sensing
Line undervoltage (UV) detection prevents turn-off glitches
Line overvoltage (OV) shutdown extends line surge limit
Accurate programmable current limit
Optimized line feed-forward for line ripple rejection
132 kHz frequency (254Y-258Y and all E/L packages) reduces transformer and power supply size
Half frequency option for video applications
Frequency jttering reduces EMI filter cost
Heatsink is connected to SOL JRCE for low EMI
Improved auto-restart delivers <3% of maximum power in short circuit and open loop fault conditions
Accurate hysteretic thermal shutdown function automatically recovers without requiring a reset
Fully integrated soft- start for minimum start-up stress
Extended creepage between DRAIN and all other pins improves field relibility
