제품 상세 정보:
|
| 부품 번호: | TMS320F28062PZT | 핵심: | C28x |
|---|---|---|---|
| 최대 클록 주파수: | 90 마하즈 | I/O의 수: | 54 입출력 |
| 프로그램 메모리 크기: | 128 KB | ADC 채널의 수: | 16채널 |
TMS320F28062PZT Microcontroller MCU C2000 Real Time Microcontrollers 90MHz 32-Bit MCU
Product Description Of TMS320F28062PZT
TMS320F28062PZT is C2000™ 32-bit Microcontroller MCU with 90 MHz, FPU, 128 KB flash, 52 KB RAM.
Specification Of TMS320F28062PZT
|
Series
|
C2000™ C28x Piccolo™
|
|
Core Processor
|
C28x
|
|
Core Size
|
32-Bit
|
|
Speed
|
90MHz
|
|
Connectivity
|
CANbus, I2C, McBSP, SCI, SPI, UART/USART
|
|
Peripherals
|
Brown-out Detect/Reset, DMA, POR, PWM, WDT
|
|
Number of I/O
|
54
|
|
Program Memory Size
|
128KB (64K x 16)
|
|
Program Memory Type
|
FLASH
|
|
RAM Size
|
26K x 16
|
|
Voltage - Supply (Vcc/Vdd)
|
1.71V ~ 1.995V
|
|
Data Converters
|
A/D 16x12b
|
|
Oscillator Type
|
Internal
|
|
Operating Temperature
|
-40°C ~ 105°C (TA)
|
|
Mounting Type
|
Surface Mount
|
|
Supplier Device Package
|
100-LQFP (14x14)
|
|
Package / Case
|
100-LQFP
|
Features Of TMS320F28062PZT
High-efficiency 32-bit CPU (TMS320C28x)
90 MHz (11.11-ns cycle time)
16 × 16 and 32 × 32 Multiply and Accumulate (MAC) operations
16 × 16 dual MAC
Harvard bus architecture
Atomic operations
Fast interrupt response and processing
Unified memory programming model
Code-efficient (in C/C++ and Assembly)
Floating-Point Unit (FPU)
Native single-precision floating-point operations
Programmable Control Law Accelerator (CLA)
32-bit floating-point math accelerator
Executes code independently of the main CPU
Viterbi, Complex Math, CRC Unit (VCU)
Extends C28x instruction set to support complex multiply, Viterbi operations, and Cyclic Redundency Check (CRC)
Embedded memory
Up to 256KB of flash
Up to 100KB of RAM
2KB of One-Time Programmable (OTP) ROM
6-channel Direct Memory Access (DMA)
Low device and system cost
Single 3.3-V supply
No power sequencing requirement
Integrated power-on reset and brownout reset
Low-power operating modes
No analog support pin
Up to 4 High-Resolution Capture (HRCAP) modules
Up to 2 Enhanced Quadrature Encoder Pulse (eQEP) modules
12-bit Analog-to-Digital Converter (ADC), dual Sample-and-Hold (S/H)
Up to 3.46 MSPS
Up to 16 channels
