제품 상세 정보:
|
| 부품 번호: | IPB117N20NFD | Vds - 드레인-소스 항복 전압: | 200 Ｖ |
|---|---|---|---|
| Id - 연속배수 경향: | 84 A | Rds에 - 드레인-소스 저항: | 10.3 모엠에스 |
| 큐그 - 게이트전하: | 87nC | PD- 전력 소산: | 300 w |
| 강조하다: | 200V MOSFET Transistor,84A Power Transistor,10.3 mOhms Integrated Circuit Chip |
||
| Series | OptiMOS™ |
|---|---|
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 200 V |
| Current - Continuous Drain (Id) @ 25°C | 84A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 11.7mOhm @ 84A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 270µA |
| Gate Charge (Qg) (Max) @ Vgs | 87 nC @ 10 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 6650 pF @ 100 V |
| Power Dissipation (Max) | 300W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TO263-3-2 |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Part Number | Package |
|---|---|
| HMC753LP4E | 24-TFQFN |
| HMC506LP4ETR | 24-VFQFN |
| MAX2615ETA | 8-WFDFN |
| ADL5604ACPZ | 16-LFCSP-VQ |
| HMC452ST89ETR | TO-243AA |
| HMC390LP4ETR | 24-QFN |
| HMC386LP4ETR | 24-VFQFN |
| HMC373LP3ETR | 16-VFQFN |
| ADL5724ACPZN | 8-UFDFN |
| HMC326MS8GETR | 8-TSSOP |
| ADL5721ACPZN-R7 | 8-UFDFN |
| HMC625BLP5ETR | 32-VFQFN |
| ADA4961ACPZN-R7 | 24-WFQFN |
| ADRF6520ACPZ | 32-LFCSP |
| HMC326MS8GTR | 8-MSOPG |
| HMC902LP3ETR | 16-QFN |
| HMC507LP5ETR | 32-VFQFN |
| HMC952ALP5GETR | 24-VQFN |
| HMC753LP4ETR | QFN-24 |
| HMC772LC4TR | QFN-24 |
| HMC1099PM5ETR | LFCSP-32 |
| HMC606LC5TR | CLCC-32 |
| HMC637ALP5ETR | QFN-32 |
| HMC462LP5ETR | QFN-32 |
| HMC460LC5TR | CLCC-32 |
| HMC6380LC4BTR | CLCC-24 |
| HMC465LP5ETR | QFN-32 |
| HMC441LP3E | 16-VFQFN |
| HMC383LC4 | 24-TFQFN |
| HMC907APM5E | 32-LFQFN |
