제품 상세 정보:
|
| 부품 번호: | STM8S105C6T3 | 프로그램 메모리 크기 :: | 32 KB |
|---|---|---|---|
| 데이터 RAM 크기 :: | 2 KB | 최대 클록 주파수 :: | 16 마하즈 |
| ADC 해상도 :: | 10 비트 | I/O 수:: | 38 I/O |
| 강조하다: | 8-Bit Microcontroller MCU,16MHz Microcontroller MCU,32KB Flash Microcontroller MCU |
||
STM8S105C6T3 is a high-performance 8-bit microcontroller from STMicroelectronics' mainstream access series. It employs the advanced STM8 core architecture with a maximum operating frequency of 16MHz, integrating 32KB flash memory, 2KB RAM, and 1KB real data EEPROM. The device offers extensive peripheral resources and industrial-grade reliability. Housed in a 48-pin LQFP package (7mm * 7mm), this device operates within a temperature range of -40°C to +125°C and supports a wide operating voltage range of 2.95V to 5.5V. It represents an ideal cost-effective embedded control solution for industrial control, automotive electronics, consumer electronics, and IoT terminal devices.
| Core Processor | STM8 |
|---|---|
| Core Size | 8-Bit |
| Speed | 16MHz |
| Connectivity | I2C, IrDA, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 38 |
| Program Memory Size | 32KB (32K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 1K x 8 |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.95V ~ 5.5V |
| Data Converters | A/D 10x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
