제품 상세 정보:
|
| 부품 번호: | IPD90P04P4L-04 | 트랜지스터 극성: | P-채널 |
|---|---|---|---|
| Vds - 드레인 소스 항복 전압: | 40 Ｖ | Id - 연속 드레인 전류: | 90 a |
| Rds On - 드레인 소스 저항: | 6.6 모엠에스 | Qg - 게이트 요금: | 135 nC |
| 강조하다: | 40V MOSFET Transistor,90A Integrated Circuit Chip,P-Channel Automotive MOSFET |
||
| Parameter | Value |
|---|---|
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 90A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 4.3mOhm @ 90A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 176 nC @ 10 V |
| Vgs (Max) | +5V, -16V |
| Input Capacitance (Ciss) (Max) @ Vds | 11570 pF @ 25 V |
| Power Dissipation (Max) | 125W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TO252-3-313 |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Part Number | Package |
|---|---|
| STPS40150CGY | TO-263-3 |
| VN9012AJTR | PowerSSO-16 |
| MASTERGAN4LTR | 31-VQFN |
| MASTERGAN1LTR | 31-VQFN |
| L99H92QF | 32-QFP |
| VN9004AJTR | PowerSSO-16 |
| VN9D5D20FNTR | QFN |
| L99H92Q5 | 32-QFN-EP |
| VNQ9080AJTR | PowerSSO-16 |
| L99MOD54XPTR | PowerSSO-36 |
| L99MOD53XPTR | PowerSSO-36 |
| VN7140AS12TR | 8-SOIC |
| MASTERGAN4TR | 31-VQFN |
| MASTERGAN5TR | QFN-31 |
| RHRPM4424LK02V | Flat-10 |
| STGAP1BS | 24-SOIC |
| STGAP4S | SO-36W |
| VND5E050MCJTR | 12-PowerLSOP |
| VN9D5D20FTR | 32-QFN |
| L7983PU33R | 10-DFN |
| L6981N50DR | 8-SOIC |
| L7983PU50R | 10-WFDFN |
| L6983N33QTR | 16-WFQFN |
| L6981C50DR | 8-SOIC |
| L6982N50DR | 8-SOIC |
| L6981N33DR | 8-SOIC |
| L6981C33DR | 8-SOIC |
| L6983IQTR | 16-WFQFN |
| L6982C50DR | 8-SOIC |
| L6982C33DR | 8-SOIC |
