제품 상세 정보:
|
| 부품 번호: | 10061913-120TLF | 판 두께 :: | 1.56mm |
|---|---|---|---|
| 현재 등급:: | 1.1 A | 절연 저항 :: | 1GΩ |
| 최대 작동 온도:: | + 85C | 최소 작동 온도:: | - 55 Ｃ |
10061913-120TLF Connectors 8Gb/s PCI Express Gen 3 Card Edge Connectors
Product Description Of 10061913-120TLF
10061913-120TLF 1.00mm pitch, vertical card edge connectors enable PcI Express@(PClee) signalling from 2.5Gb/s (Gen 1) and 5Gb/s (Gen 2) up to 8Gb/s (Gen 3) per differential signal pair. A modular design of these connectors allow standard pin counts like 36,64,98,164 and 280.
The basic bandwidth (x1) version supports a single PCI Express@ lane and is typically used for I/0 cards in desktop PCs.The x4 and x8 connectors provide 64 and 98 contacts respectively for server I/0. The high bandwidth versions (x16 lanes and higher) are used for higher bandwidth applications like graphics cards in PCs or riser cards in servers.
Specifications Of 10061913-120TLF
|
Card Type
|
PCI Express™
|
|
Gender
|
Female
|
|
Number of Positions
|
36
|
|
Card Thickness
|
0.062" (1.57mm)
|
|
Number of Rows
|
2
|
|
Pitch
|
0.039" (1.00mm)
|
|
Read Out
|
Dual
|
|
Features
|
Board Guide, Locking Ramp, Solder Retention
|
|
Mounting Type
|
Surface Mount
|
|
Termination
|
Solder
|
|
Contact Material
|
Copper Alloy
|
|
Contact Finish
|
Gold
|
|
Contact Finish Thickness
|
Flash
|
|
Contact Type
|
Cantilever
|
|
Color
|
Black
|
|
Operating Temperature
|
-55°C ~ 85°C
|
Features Of 10061913-120TLF
Connector range offers x1,x4,x8,orx16 serial PCle links
200, 230(x24), and 280 position vertical connectors available
ExpressModule" versions provide an expanded lead-in window
Straddle mount connectors featuring mounting ears
Integrate rugged stand-alone retention mechanism
Benefits Of 10061913-120TLF
Supports different bandwidth requirements
Supports PCand server riser cards
Supports blind mate server applications
Assures proper alignment to the host PCB
Secures graphics cards during shipping and handling
Applications Of 10061913-120TLF
Desktop PC
Server
Workstation
