제품 상세 정보:
|
| 부품 번호: | 2322946-2 | 위치 수: | 6 |
|---|---|---|---|
| 접속 시스템: | 와이어 대 보드 | 행의 수: | 1 |
| 중심선(피치): | 6.35mm[0.25인치] | PCB에 대한 종단 방법: | 스루홀 - 솔더 |
2322946-2 Connectors 6POS Automotive Headers 90 Degree Headers Wire-To-Board Connectors
Product Description Of 2322946-2
2322946-2 is 90 Degree Automotive Headers, Horizontal, Wire-To-Board Connectors, 6 Position, 1 Row, Printed Circuit Board, 1A Contact Current Rating (Max), Signal.
Specification Of 2322946-2
|
Connector Type
|
Header
|
|
Pitch - Mating
|
0.250" (6.35mm)
|
|
Number of Positions
|
6
|
|
Number of Rows
|
1
|
|
Number of Positions Loaded
|
All
|
|
Style
|
Board to Cable/Wire
|
|
Shrouding
|
Shrouded - 4 Wall
|
|
Mounting Type
|
Through Hole, Right Angle
|
|
Termination
|
Solder
|
|
Fastening Type
|
Push-Pull
|
|
Contact Length - Post
|
0.118" (3.00mm)
|
|
Insulation Height
|
0.331" (8.40mm)
|
|
Contact Shape
|
Rectangular
|
|
Contact Finish - Mating
|
Tin
|
|
Contact Finish - Post
|
Tin
|
|
Contact Material
|
Copper Alloy
|
|
Insulation Material
|
Polyphthalamide (PPA), Glass Filled
|
|
Features
|
Board Guide
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
Insulation Color
|
Orange
|
|
Current Rating (Amps)
|
1A
|
|
Voltage Rating
|
1000VDC
|
Features Of 2322946-2
Number of positions: 6
Number of rows: 1
Pitch: 6.35 mm (0.250")
Mounting: Horizontal / 180° through-hole
Termination: PCB Through-hole
Contact Type: Male Pin
Housing Colour: Orange
Contact Material: Tin (Sn) Plated
Rated Current: 1 A (Maximum)
Product Photo Of 2322946-2
