제품 상세 정보:
|
| 부품 번호: | AD637JRZ | 현재 - 공급: | 2.2 마 |
|---|---|---|---|
| 전압 - 공급: | ±3V ~ 18V | 출력 전류: | 6mA |
| 최대 출력 전압: | 12V | 입력 전압 범위: | - 8V ~ 8V |
AD637JRZ Integrated Circuit Chip 2.2mA High Precision Wideband RMS-To-DC Converter SOIC16
Product Description Of AD637JRZ
AD637JRZ is a complete, high accuracy, rms-to-dc converter that computes the true rms value of any complex waveform. It offers performance that is unprecedented in integrated circuit rms-to-dc converters and comparable to discrete and modular techniques in accuracy, bandwidth, and dynamic range.
AD637JRZ computes the true root mean square, mean square, or absolute value of any complex ac (or ac plus dc) input waveform and gives an equivalent dc output voltage. The true rms value of a waveform is more useful than an average rectified signal because it relates directly to the power of the signal. The rms value of a statistical signal relates to the standard deviation of the signal.
Specification Of AD637JRZ
| Converters | |
| SMD/SMT | |
| SOIC-16 | |
| 6 mA | |
| 8 V | |
| - 8 V | |
| 12 V | |
| - 55 ℃ | |
| + 125 ℃ | |
| 2.2 mA | |
| Input Voltage Range: | - 8 V to 8 V |
| Operating Supply Voltage: | 3 V to 18 V |
| Output Voltage Range: | 0 V to 12 V |
Features Of AD637JRZ
High accuracy
0.02% maximum nonlinearity, 0 V to 2 V rms input
0.10% additional error to crest factor of 3
Computes
True rms
Square
Mean square
Absolute value
dB output (60 dB range)
Wide bandwidth
8 MHz at 2 V rms input
600 kHz at 100 mV rms
Chip select/power-down feature allows
Analog three-state operation
Quiescent current reduction from 2.2 mA to 350 μA
