제품 상세 정보:
|
| 부품 번호: | HCNW3120-500E | 전압 - 절연: | 5000Vrms |
|---|---|---|---|
| (민) 공통 모드 트랜지엔트 면역: | 25kV/us | 전달 지연 트플에 / 티피하들 (맥스): | 500 나노 초, 500 나노 초 |
| 펄스 폭 왜곡 (맥스): | 300ns | 상승 / 낙하 시간 (타이핑): | 100 나노 초, 100 나노 초 |
HCNW3120-500E contains a GaAsP LED while the HCPL-J312 and the HCNW3120-500E contain an AIGaAs LED. The LED is optically coupled to an integrated circuit with a power output stage. These optocouplers are ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications.
The high operating voltage range of the output stage provides the drive voltages required by gate controlled devices. The voltage and current supplied by these optocouplers make them ideally suited for directly driving IGBTs with ratings up to 1200V/100A. For IGBTs with higher ratings, the HCPL-3120 series can be used to drive a discrete power stage, which drives the IGBT gate.
| Parameter | Value |
|---|---|
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 25kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 500ns, 500ns |
| Pulse Width Distortion (Max) | 300ns |
| Rise / Fall Time (Typ) | 100ns, 100ns |
| Current - Output High, Low | 2A, 2A |
| Current - Peak Output | 2.5A |
| Voltage - Forward (Vf) (Typ) | 1.6V |
| Current - DC Forward (If) (Max) | 25 mA |
| Voltage - Output Supply | 15V ~ 30V |
| Operating Temperature | -40°C ~ 100°C |
