LPC802M001JDH20 Microcontroller MCU 32-Bit Microcontroller Based On Arm Cortex-M0+ Core

LPC802M001JDH20 is a cost-effective 32-bit MCU series based on the Arm Cortex-M0+, operating at frequencies up to 15 MHz. The LPC80x MCU series supports up to 32 KB of flash memory and 4 KB of SRAM.

LPC802M001JDH20 features a power-optimised core, utilises a popular small-footprint package, and supports level shifting via a separate power rail. The LPC80x peripheral suite includes: a CRC engine, an I²C bus interface, up to two USARTs, an SPI interface, a capacitive touch interface, a multi-rate timer, a wake-up timer, a general-purpose 32-bit counter/timer, a 12-bit ADC, a 10-bit DAC, an analogue comparator, I/O ports with switch-matrix configurable functionality, an input mode matching engine, a programmable logic unit (PLU), and up to 30 general-purpose I/O pins.

• Arm Cortex-M0+ processor (version r0p1), operating at frequencies up to 15 MHz, with integrated single-cycle multiplier and fast single-cycle I/O ports
• Arm Cortex-M0+ with built-in Nested Vector Interrupt Controller (NVIC)
• System clock and AHB multi-level bus
• Serial Wire Debug (SWD) with four breakpoints and two watchpoints; supports JTAG Boundary Scan (BSDL)
• Up to 32 KB of on-chip flash programmable memory with Code Read Protection (CRP)
• Up to 4 KB of SRAM
• Dual I/O power supplies supporting level-shifting signals between different power domains
• Single or dual power supply (1.71 V to 3.6 V)
• Operating temperature range: -40 °C to +105 °C

• Industrial control
• POS terminals
• Home control panels
• Home energy displays
• Smartwatches and fitness trackers
• Surveillance
• Vital signs monitors
• Motion control and robotics
• Consumer electronics
• Hearing aids
• Air conditioning (AC)
